General view of instruments and operating elements
50
BA RD24_RD28 en us 06
Driver's seat, model C
17963
521 525
522
520
[520] Seat adjustment weight [521] Seat adjustment forward -
backward
[522] Seat backrest adjustment [525] Seat adjustment left - right
Normal mode control unit
17248
101
301 304
118 216 237
[101] Hourmeter indicator [118] Display of diagnostic code
[216] Pilot light, cold start assistance [237] Fuel level pilot light
[301] Signal horn switch [304] Parking brake switch
