Operation RD 27
32 wc_tx000814gb.fm
4.8 Adjusting the Seat
Background
Adjust the seat position and tension (firmness) according to working conditions and
operator’s weight.
To adjust
The seat can be adjusted in three ways:
Tension Use knob (a) for adjusting seat tension. Turn from a minimum of
60 kg to a maximum of 120 kg (132 lb–264 lb).
Front to back Use lever
(b) to adjust the front-to-back distance from the driving
controls.
Side to side (optional) Use pin
(c) to set one of the three side-to-side position place-
ment holes (if so equipped).
To Next Page
