Maintenance RD 27
66 wc_tx000815gb.fm
5.12 Checking Hydraulic Oil Level
Prerequisites
Machine shut down
Hydraulic oil warm
When
Every 10 hours of service or daily
l
Procedure
Follow the procedure below to check the hydraulic oil level.
1. Open the engine compartment.
2. Observe the hydraulic oil level through the sight gauge (a).
3. If the oil level is low, open the reservoir cap (b) and fill the hydraulic oil to the
mark on the sight gauge.
b
