WAGNER Cobra 40-10 Operating Manual

37
Cobra.
OPERATING MANUAL
EDITION 01/2012
PART NUMBER DOC322851
7 ACCESSORIES
7.1 COBRA 40-10 ACCESSORIES
List accessories Cobra 40-10
Pos K
Part No. Description
A 322040 Diaphragm pump Cobra 40-10
1
◆
322912 Hydraulic fl uid (for pressure stage) 250 ml; 250 cc
2
◆
236219 Earthing cable 3 m; 9.8 ft
3 322050 Filter pressure regulator with plastic bow
4 341434 Double open ended spanner
5
◆
115985 Container metal for fi lter pressure regulator
6
◆
322053 High pressure fi lter 3/8“ (without ball valve)
7 367115 Wall mounting complete for high pressure fi lter
8
◆
9925024 Sealing ring Cu
9
◆
9974112 Sealing ring Al
10 2311833 Return tube assy.
11 2311834 Filter G1/2”, mesh width 0.8 mm; 0.04 inch
12 367141 Return hose DN 13; ID 0.51 inch, M20x2
13 2311832 Suction system assy.
14 340908 Return tube for pos. 15
15 341267 Upper hopper set Ex 5 L; 1.3 gal
16 322052 Frame assy.
17 2311835 Flexible suction hose (rotatable) DN 16; ID 0.63 inch
21 367020 Wall mounting
24
◆
97531 Suction fi lter bag MW 0.3; MW 0.012 inch
25 367121 Stand with wheels assy.
26 369657 Double nipple A=G3/4“ -A=NPSM3/8”
27 367563 Adapter RF FM 3/8“ NPS M16x1.5 PN530-SSt
30
◆
2313585 AirCoat spray gun GM 4700AC, 25 MPa; 250 bar; 3626 psi, NPSM1/4“
31
◆
2309705 Hose set material AC
Material: NPSM1/4“, 7.5 m; 24.6 ft, DN 3 mm; ID 0.12 inch, 27 MPa; 270 bar; 3916 psi
Air: G1/4“, 7.5 m; 24.6 ft, DN 6 mm; ID 0.24 inch, 0.8 MPa; 8 bar; 116 psi
32
◆
394012 AirCoat spray gun GM 4100AC, 25 MPa; 250 bar; 3626 psi, NPSM1/4“
33
◆
379HHH Nozzles ACF3000 -> see nozzle list in gun manual
34 394910 Air cap LV (red)
35 394911 Air cap HV (blue)
36
◆
2309706 Hose set material AC
Material: NPSM1/4“,7.5 m; 24.6 ft, DN 4 mm; ID 0.16 inch, 27 MPa; 270 bar; 3916 psi
Air: G1/4“, 7.5 m; 24.6 ft, DN 6 mm; ID 0.24 inch, 0.8 MPa; 8 bar; 116 psi
◆ = Wearing parts
