WAGNER Cobra 40-10 Operating Manual

13
Cobra.
OPERATING MANUAL
EDITION 01/2012
PART NUMBER DOC322851
4.3 DATA
4.3.1 MATERIALS OF PAINT WETTED PARTS
Inlet housing Consital®
Material pump Consital®
Valve balls
Stainless steel
Valves seats/ cone valve
Tungsten carbide
Diaphragm
PA consistent
Valve fi tting
1.4104
4.3.2 TECHNICAL DATA
Description Units Cobra 40-10 Cobra 40-25
Transmission ratio 40 :1 40 :1
Flow volume per double stroke (DS) cm
3
cu inch
10
0.6
25
1.5
Maxi. operating pressure MPa
bar
psi
25
250
3626
25
250
3626
Maxi. possible strokes in operation DS/min 200 200
Min. - Maxi. air inlet pressure MPa
bar
psi
0.25-0.6
2.5-6
36.3-87
0.25-0.6
2.5-6
36.3-87
4.2 SCOPE OF SUPPLY
Part No. Qty Description
322040 1 Diaphragm pump Cobra 40-10 consisting of:
Material pump, air motor, connection elements
322102 1 Diaphragm pump Cobra 40-10 on frame consisting of:
Material pump, air motor, connection elements
2308721 1 Diaphragm pump Cobra 40-25 consisting of:
Material pump, air motor, connection elements
2308722 1 Diaphragm pump Cobra 40-25 on frame consisting of:
Material pump, air motor, connection elements
The standard equipment includes:
322981 1 Information plate
236219 1 Earthing cable assy.
341434 1 Double open ended spanner
See chap. 3 1 Certifi cate of conformity
322850 1 Operating manual German
See chap. 1 1 Operating manual in the local language:
The delivery note shows the exact scope of delivery.
Accessories see chapter 7.
