WAGNER Cobra 40-10 Operating Manual

45
Cobra.
OPERATING MANUAL
EDITION 01/2012
PART NUMBER DOC322851
8.3 COBRA 40-10 AIR MOTOR
Pos K Qty Part No. Description
1 1 9998718 Pin
2 1 367318 Shoulder screw 4
3 1 9925033 Washer
4 1 367311 Cover 4
5
◆
1 367319 Acoustical foam mat 4
6 1 9999152 Velcro fastener coating part
7 1 9999151 Velcro fastener adhesive part
8 1 367318 Shoulder screw 4
9 1 9925033 Washer
10 1 367310 Silencer 4
11
◆★
1 9974098 O-ring
12
◆★
1 9974097 O-ring
13 3 9900325 Cheese-head screw
14 3 9920103 Washer A6.4
15 1 367309 Connection piece 4
16 2 367320 Spring connector
17 1 369290 Pilot valve
18 2 9998674 Threaded plug
19 1 9998274 Threaded plug
20 1 367315 Control housing 4
21
◆★
1 367313 Filter air pressure 4/6
22 1 322060 Pressure control unit 3 assy.
23 4 9900316 Cheese-head screw
24 1 322429 Pressure gauge restrictor
25 1 9999228 Screwed connection L
26 2 367307 Lock plug 4/6
27
◆★
2 9974085 O-ring
28 1 367324 Filter location
29
◆★
1 367314 Filter control air
30
◆★
1 322910 Set Seal, outlet Cobra (consisting for 2 seals)
31
◆★
2 9974095 O-ring
32 1 368285 Safety valve 0.63 MPa; 6.3 bar; 91 psi
33
◆
1 9943080 Spool and sleeve assembly
34
◆
1 368038 Detent body, assy. ISO 1/2
35 2 9907126 Screw SFS Plastite 45
36
◆★
1 9974089 O-ring
◆ = Wearing part ★ = Included in service set
● = Not part of standard equipment. Available, however, as additional extra
