8.17 UPPER HOPPER ASSY.
Pos K Qty Part No. Description
1 2311832 Suction system assy.
2 1 2311833 Return pipe
3 1 2311834 Suction fi lter
8.16 COBRA 40-10 AND 40-25 SUCTION SYSTEM
Pos K Qty Part No. Description
1 1 341267 Upper hopper set Ex, 5 L; 1.3 gal
2 2 9902306 Combination sheet metal screw
3 1 3756 Filter disk
Mesh 0.4 mm; 0.02 inch
3a 1 37607 Filter disk
Mesh 0.8 mm; 0.03 inch
4 1 340265 Upper hopper Ex
5 1 340908 Return pipe
6 1 340429 Cover
