69
Cobra.
OPERATING MANUAL
EDITION 01/2012
PART NUMBER DOC322851
Pos K Qty Part No. Description
1 1 2311185 High pressure fi lter set HPF-3 3/8“ NPS
2 1 367911 Filter housing
3 1 367912 Union nut
4 2 367556 Double fi tting DF MM G3/8“-3/8“ NPS PN530-SSt
5
◆
1 367914 O-ring
6 1 367910 Distribution housing
7 1 9894245 Filter support
8
◆
1 - Filter cartridges *
295721 * Filter cartridge 200
3514068 * Filter cartridge 100
3514069 * Filter cartridge 50
291564 * Filter cartridge 20
9
◆
1 3514058 Cone spring
10 3 9907127 Lock screw
11 1 2311174 Angle bracket
12
◆
2 9925024 Sealing ring Cu
13
◆
2 9974111 Sealing ring Al
14 2 9920103 Washer
15 4 9921502 Spring ring
16 4 9900111 Hexagon screw
17 1 2307608 Bend 90° MF 3/8“ NPS 3/8“ NPS PN530-SSt
18
◆
1 2311459 High pressure hose DN10 PN530 NPS 3/8 0.6 m; 1.97 inch PA
◆ = Wearing part
