EPG-SPRINT XE
OPERATING MANUAL
VERSION 09/2017 ORDER NUMBER DOC2354913
Section Type of inspection Requirements Inspection
by
Type of inspection Inspection
interval
4 Eectiveness of grounding All the system's conductive
elements, such as oors, walls, ceilings, protective grating,
transport equipment, work
pieces, powder tanks, machines or
construction parts etc. in the spray
area, with the exception of parts
which carry high voltage during
operation, must be connected to
the grounding system. Parts of the booth must be grounded in
accordance with EN 12215.
SP
VI/ME/CM
Visual check of ground
connections, perform function
test on grounding switch,
measurement of grounding resistors.
weekly
5 Measures to take if conductive
components are insuciently grounded
If sucient grounding of
conductive parts cannot be ensured, their discharge energy
must not exceed the permissible
value.
SP ME/CM
Measurement of discharge
energy.
weekly
6 Ground leaking resistance from the
work piece attachment point
The resistance to ground of
every work piece's locating point
must not exceed 1 megohm
(measurement voltage must be
1000 V). The form of construction
of the work piece mount must guarantee that the work pieces
remain grounded during coating.
SP ME/CM
Measure resistance to ground
(work piece receiver - ground
potential) max. 1 megohm @ 1000 V.
weekly
Legend:
MF = Manufacturer
ER = Employer
SP = Skilled person
FPO = Fire prevention ocer ELT = Electrician
TP = Trained person
FT = Function test
ME = Measurement
OC = Organization check VI = Visual inspection CM = Constant monitoring
TT = Technical testing
