WAGNER PEM-C4-Ergo User Manual

13
PEM-C4-Ergo.
OPERATING MANUAL
VERSION 02/2009
ORDER NUMBER DOC2305054
Dimensions:
Length/width/height see chapter 4.3.1
Weight 504 g; 1.11 lbs
Electrical:
Input voltage max. 22 Vpp
Input current max. 0.9 A
Frequency 19-30 kHz
Output voltage max. 100 kV DC
max. Corona current 120 µA
Polarity negative
Design as per EN 50050
Protection class IP 54
Pneumatic:
Compressed air input pressure
(atomizing air quantity)
max. 3 bar; 0.3 MPa, 43.51 psi
Powder output quantity max. 450 g/min; max. 0.99 lbs/min.
Operating temperature range 5-45°C; 41-113°F
4.3 TECHNICAL DATA
SIHI_05034_ENG
WARNING
Outgoing air containing oil!
Risk of poisoning if inhaled
 Provide water-free and oil-free compressed air (quality standard
3.5.2 as per ISO 8573.1) 3.5.2 = 5 μm / +7°C; 44.6°F / 5mg/m³.
Ambient conditions:
If low temperature powders are used,the ambient temperature may have to be lower than
30°C; 86°F.
Volume measures:
For volumes,specified in Nm³ (standard cubic meters).One cubic meter of a gas at 0°C;32°F
and 1.013 bar is called norm cubic meter. 1 Nm³/h = 35.3ft³/h; 1 bar = 14.504 psi.
