10. The spray gun is ready for use again.
Hint:
Into the extension also a round spray nozzle can
be installed.
The proceeding is described in the chapter 7.4
“Fitting the round spray nozzle“.
5. Unscrew the outer nut 11 from the extension 12.
6. Slide the extension 12 over the gun housing 5
and tighten it.
7. Carefully fi t the electrode holder 3 into the
extension 12.
8. Slide the fan spray nozzle 2 over the electrode
holder 3.
9. Tighten the outer nut 11.
