Safety Instructions C23i
18
2.
3.
1.
4.
5.
6.
Location: RH Fender
Part Number: 8600-68
SAFETY, CONTROL, AND INSTRUCTION DECALS
Safety, Control, and Instruction Decals are installed on the machine;
if any are missing, illegible, or damaged, a replacement should be ordered and installed before
putting the machine into operation. The Decal Part Number is listed below and in the Parts Manual.
1. Warning – read Operator’s Manual before
servicing or performing maintenance.
● Engage parking brake.
● Remove ignition key.
2. Forward Speed Control
● Move lever forward to increase speed; back
to stop.
3. Warning – roll-over hazard.
● Do not mow or drive the tractor within 5 feet
of an embankment with a drop o.
● Do not operate on slopes greater than 15
degrees.
● Do not mow within 5 feet of a body of water.
4. Throttle
● Move lever forward to increase engine
speed; back to idle.
5. Warning – do not operate the machine without
a deck or other implement attached.
6. Seat Panel Latch
● Move lever backward to release.
● Lift seat panel to raise.
1.
2.
Location: Underside of Seat Panel
Part Number: 6107
1. Ground drive belt routing.
2. Engine belt routing.
