Familiarization
FX85, FX110, FX140
Skidding Winch
16
4. Familiarization
IMPORTANT! Before starting work with the winch, become
familiar with the location and function of all controls.
4.1 New Operator
It is the responsibility of the owner or operator to read this
manual and to train all other operators before they start working
with the machine. Follow all safety instructions exactly.
By following recommended procedures, a safe working
environment is provided for the operator, bystanders and the
area around the work site. Untrained operators are not qualified
to use the machine.
4.2 Operator Orientation
IMPORTANT! When describing controls as mentioned
throughout this manual, the directions for left-hand, right-
hand, backward and forward, are determined when sitting in
the tractor seat, facing the direction of forward travel.
Figure 4 – Direction of forward travel
Each operator must be trained in the correct operating
procedures before using the machine. The Sign-Off Form on
page 10 can be used to keep a training record.
1. Teach the new operator the control locations, functions,
and movement directions.
2. Put the machine in a large open area and let the new
operator learn the control functions and machine
responses.
3. After the new operator knows and is comfortable with the
machine, they can start work.
4.3 Work Site Familiarization
It is the responsibility of the operator to be thoroughly familiar
with the work site before operating the machine. Some items the
operators should check include but are not limited to:
1. Make sure that there is a sufficient amount of space and
clearance for the machine to winch the load.
2. Organize the work area to minimize the winch and log
removal distances. The shorter the distances, the faster the
work will be finished.
3. Use care when pulling logs off of a pile. The logs can
roll when you attach the cable or winch rope, or during
operation.
4. Position the tractor so prevailing winds blow engine exhaust
fumes away from operator.
