Specifications
FX85, FX110, FX140
Skidding Winch
52
11. Specications
For available accessories, go to WallensteinEquipment.com.
11.1 Machine Specifications
1
Specification FX85 / FX85R
FX85S /
FX85RS
FX110 /
FX110R
FX110S /
FX110RS
FX140 /
FX140R
FX140S /
FX140RS
Weight 470 lb (213 kg) 796 lb (361 kg) 898 lb (407 kg)
Machine dimensions
L x W x H
27" x 40" x 76"
(68 x 101 x 193 cm)
28" x 50-1/2" x 79"
(71 x 128 x 200 cm)
28" x 58-1/2" x 80"
(71 x 149 x 203 cm)
Pulling capacity 8,500 lb (3 855 kg) 11,000 lb (4 989 kg) 14,000 lb (6 350) kg
Horsepower range 30–60 hp (13–45 kW) 45–100 hp (34–75 kW) 60–140 hp (45–104 kW)
PTO input speed
(maximum)
540 rpm
Winch type Mechanical, dry disk adjustable clutch
Winch line speed 96–238 ft/min (29–72 m/min) 98–253 ft/min (30–77 m/min) 98–246 ft/min (30–75 m/min)
Steel cable length 165 ft (50 m) N/A
2
165 ft (50 m) N/A 165 ft (50 m) N/A
Steel cable maximum
length capacity
239 ft (73 m) N/A 207 ft (63 m) N/A 165 ft (50 m) N/A
Steel cable diameter 7/16" (11 mm) N/A 1/2" (12.7 mm) N/A 1/2" (12.7 mm) N/A
Synthetic winch rope
length
N/A 200 ft (61 m) N/A 200 ft (61 m) N/A 200 ft (61 m)
Synthetic winch rope
diameter
N/A 7/16" (11 mm) N/A 1/2" (12.7 mm) N/A 1/2" (12.7 mm)
Maximum input torque 265 lbf•ft (360 N•m) 351 lbf•ft (476 N•m) 450 lbf•ft (610 N•m)
Maximum bare drum
pull
8,553 lb (3 879 kg) 11,130 lb (5 048 kg) 14,053 lb (6 374 kg)
Maximum full drum pull 2,992 lb (1 357 kg) 3,673 lb (1 666 kg) 4,733 lb (2 146 kg)
Hydraulic flow
necessary for the
remote control
(FX-R and FX-RS models
only)
1–2 gpm (3.8–7.6 Lpm)
Mounting system
category
CAT I CAT I and II CAT II
1 Specifications subject to change without notice.
2 N/A indicates that a specification is not applicable.
