07610-003-67-17-K
31
FRAME & MOTOR ASSEMBLY
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Discharge Tube Connector 05700-011-70-34
2 1 Pump Suction Hose 05700-002-40-82
3 1 Discharge Hose Assembly 05700-002-45-58
3a 2 Fitting, 1/2” Pushlock, Female, Brass 04730-011-93-99
3b 1 Hose, 1/2” x 22 1/2” 05700-002-45-59
4 1 Wash Restrictor 05700-002-84-69
5 1 Accumulator Strainer Weldment 05700-003-33-25
6 1 Accumulator Weldment 05700-002-51-95
7 8 Bolt, 1/4-20 x 1/2” 05305-274-02-00
8 18 Locknut, 1/4-20 SS Hex with Nylon Insert 05310-374-01-00
9 18 Washer, 1/4-20 SS 05311-174-01-00
10 1 Hose Clamp, 13/16” to 1 1/2” 04730-719-06-09
11 3 Hose Clamp, 1 1/16” to 2 1/4” 04730-719-18-00
12 1 Close Nipple, 1/2” Brass 04730-207-15-00
13 1 Gauge, Thermometer 06685-111-68-48
To Next Page
