Wareforce DG-E - ELECTRICAL REQUIREMENTS

07610-003-67-17-K
4
Electrical Requirements:
Wash Motor HP 0.75
Wash Heater kW 1.5
Rinse Heater kW 2 kW @ 110 V
Total Amps 16*
Typical Electrical Circuit (Amps) 20
All electrical ratings provided in this manual are for reference only. Always refer
to the machine data plate to get exact electrical information for this machine.
All electrical work performed on machines should be done in accordance
with applicable local, state, territorial, and national codes. Work should
only be performed by qualied electricians and authorized service agents.
Note that all electrical wiring used in this series of machines must be rated,
at a minimum, for 212 °F (100 °C), and that only copper conductors must be
used.
Where applicable, heating element amperage draws have been adjusted for
the assumed input voltage. The manufacturer assumes incoming voltages will
be either 208 or 230 V. Some heating elements used in the machines are rated
for other voltages, such as 240 V and 480 V. Always verify the amperage draw
of the machine in operation when sizing circuit protection.
If the dishmachine is equipped with the optional rinse heater, note the rinse
heater might have its own electrical connection and require a separate service.
Amperage loads for motors and heaters are indicated on the machine data plate.
DG-E electrical congurations:
Available Electrical Characteristics:
• 115 V, 60 Hz, Single-phase
Available Wash Tank Heaters:
• 1.5 kW
Available Rinse Tank Heaters:
• 2 kW
*The DG-E is designed so that the wash motor is never running when the
wash heater is on. Total Amps is based on the higher of the two loads.
DG-E
Electrical Characteristics
VOLTS 115
PHASE 1
FREQ 60
WASH
MOTOR
AMPS
10.0 A
WASH
HEATER
AMPS
16.0 A
TOTAL
LOAD
16.0 A*
NOTICE
i
ELECTRICAL REQUIREMENTS
SPECIFICATIONS
