Wareforce DG-E - MOTOR ASSEMBLY

07610-003-67-17-K
32
ITEM QTY DESCRIPTION PART NUMBER
Complete Pump & Motor Assembly 05700-004-29-64
1 1 Motor Only 06105-004-32-03
2
1 Case O-Ring 05330-002-81-83
1 Seal Plate 05700-002-81-87
3 1 Mechanical Seal 05330-002-34-22
4 4 Case Capscrew 05305-002-81-88
5 1 Pump Casing 05700-002-85-01
6 1 Shim Kit 05700-002-82-58
7 1 Impeller Assembly 05700-002-81-86
8 1 Drain Plug (Not Shown) 04730-002-81-89
1
7
2
6
5
3
4
MOTOR ASSEMBLY
PARTS
