WarmFlow 70/90 - Oil Supply - Two Pipe & De-aerator Systems

9.8 Fitting a Slimline Kabin Pak Vertical Flue Adaptor
Remove the flue terminal (4 screws) and fit the adaptor as shown (4 screws).
FLUE TERMINAL
VERTICAL
FLUE ADAPTOR
Note: Where there is a possibility of air being trapped in the boiler the installer must ensure
that the automatic air vent is fitted to the boiler.
Page 31
