WarmFlow 70/90 - R40 G10 Burner

15.3 Burner Spares Riello 40 – G10
NO CODE DESCRIPTION
1 3000879 Air Shutter Assembly
2 3006913 Tube
3 3005788 Fan
4 3005798 Condenser
5 3007355 Motor
6 3007077 Washer
7 3007450 Pump
8 3002279 Coil
9 3006553 Cover
10 3007028 ‘O’ Ring
11 3007162 ‘O’ Ring
12 3005719 Filter
13 3006925 Valve Stem
14 3007029 ‘O’ Ring
15 3007156 ‘O’ Ring
16 3000439 Pump Seal
17 3005789 Tube
18 3000443 Joint
NO CODE DESCRIPTION
19 3006557 Access Plate
20 3005791 Collar
21 3005764 Nozzle Holder
22 3002278 Control Box Base
23 3001156 Control Box
24 3002297 Igniter
25 3002280 Photocell
26 3005792 Head
27 3006392 Disc with Ring Pressed
28 3005795 Flange Gasket
29 3005796 Flange
30 3000640 Hinge
31 3005790 Electrode
32 3006552 Electrode Clamp
33 3009068 Connector
34 3005720 Flexible Pipe
35 3006911 Hydraulic Ram
Page 47
