WarmFlow 70/90 - R40 G20 S Burner

15.4 Riello 40 – G20S
NO CODE DESCRIPTION
1 3005799 Fan
2 3007156 ‘O’ Ring
3 3007028 ‘O’ Ring
4 3005801 Washer
5 3005800 Tube
6 3005802 Condenser
7 3007077 Washer
8 3005771 Pivot
9 3005803 Washer
10 3005804 Pivot
11 3007079 Washer
12 3005805 Connector
13 3007162 ‘O’ Ring
14 3005719 Filter
15 3006925 Valve
16 3007029 ‘O’ Ring
17 3002297 Igniter
18 3006553 Cover
19 3000439 Pump Seal
20 3005808 Tube
21 3006500 Retarder
22 3002279 Coil
23 3006924 Pump
NO CODE DESCRIPTION
24 3000443 Joint
25 3005720 Flexible Pipe
26 3005820 Motor
27 3006558 Access Plate
28 3001156 Control Box
29 3002280 Photocell
30 3002278 Control Box Base
31 3005809 Tube
32 3005810 Collar
33 3005764 Nozzle Holder
34 3006264 Ring
35 3005813 Flange Gasket
36 3005814 Flange
37 3000640 Hinge Assembly
38 3006265 Head
39 3005816 Electrodes
40 3006552 Clamp
41 3009068 Connector
42 3006499 Hydraulic Ram
43 3006501 Tube
44 3000645 Air Shutter
45 3007161 ‘O’ Ring
46 3007165 Valve Piston ‘O’
Page 48
