ENCORE
®
700 METERING PUMP
KEY NO. LEGACY PART
NO.
ALT. PART
NO.
QTY. DESCRIPTION

44
APP5655
W2T11093
1
Breather Cap
45

APS4845
W2T417684
1
Shaft, Eccentric, 4.8mm Stroke (1-3/8" & 2" Liquid End Only)
OR

ALI4852
W2T11404
1
Shaft, Eccentric, 9.6mm Stroke
46

AIA4800
W2T417615
1
Sheave, 4.8mm Stroke (1-3/8" & 2" Liquid End Only)
OR

AIA4795
W2T11341
1
Sheave, 9.6mm Stroke
...
47
ANI4750
W2T10695
1
Knob, Str., Adj., LMAD (Mach.), Manual
OR
AJA3455
W2T367021
1
Knob, Str., Adj., Auto
...
48
AAA2382
W2T11020
3
Scr., Set, M6 x 10, Flat, Skt., Nyl., 316
...
49
AXS3656
W2T11182
4
Cap., Scr., M8 x 20, Sock. Hd., 316SS
50
t
ASS3183
W2T417687
1
Drive Gear, Worm, Ratio 10 (144 SPM @ 50Hz) (5" & 6-1/2" Liquid End Only)
OR

AOK3192
W2T11323
1
Drive Gear, Worm, Ratio 12 (144 SPM) (5" & 6-1/2" Liquid End Only)
OR

ARQ3199
W2T11264
1
Drive Gear, Worm, Ratio 24 (72 SPM) (5" & 6-1/2" Liquid End Only)
OR
T
AKC3205
W2T11269
1
Drive Gear, Worm, Ratio 48 (36 SPM) (5" & 6-1/2" Liquid End Only)
OR
AAC5597
W2T416795
1
Drive Gear, Worm, Ratio 10 (144 SPM @ 50Hz) (1-3/8", 2", 3" & 4" Liquid End Only)
OR
AAC5831
W2T8583
1
Drive Gear, Worm, Ratio 12 (144 SPM @ 60Hz) (1-3/8", 2", 3" & 4" Liquid End Only)
OR
AAC5834
W2T8581
1
Drive Gear, Worm, Ratio 24 (72 SPM) (1-3/8", 2", 3" & 4" Liquid End Only)
OR
AAC5837
W2T8582
1
Drive Gear, Worm, Ratio 48 (36 SPM) (1-3/8", 2", 3" & 4" Liquid End Only)
51
t
AAA9530
W2T416692
1
Worm Shaft, Ratio 10 (144 SPM @ 50Hz)
OR

AAA9533
W2T10250
1
Worm Shaft, Ratio 12 (144 SPM @ 60Hz)
OR

AAA9536
W2T10251
1
Worm Shaft, Ratio 24 (72 SPM)
OR
T
AAA9539
W2T10252
1
Worm Shaft, Ratio 48 (36 SPM)
52
ARE3591
W2T367156
4
Scr.Cap, M8 x 40, Soc. Hd., 316SS
53
AWO5392
W2T11160
4
Washer, Flat, M8, 316SS
54
AXQ3226
W2T11183
4
Lockwasher, M8, 316SS
55
AAA1698
W2T8462
4
Nut, M8, 316SS
56
AAC7619
W2T8262
1
Metal Base, 1-3/8", 2", 3", 4" & 5" Head (Includes Key No.'s 52, 53, 54 & 55)
OR
AAC7622
W2T365189
1
Metal Base, 6-1/2" Head (Includes Key No.'s 52, 53, 54 & 55)
NOTE: e PART OF AOO4751 • PART OF AJE4758 • PART OF ANM4767
0 PART OF AAA9593 (W3T108130) D PART OF AAA9596 (W3T110122) PART OF APQ4775
PA
RT OF AAA9599 (W3T108131) PART OF AIC3164 PART OF AAA9590 (W3T108129)
WHEN ORDERING MATERIAL, ALWAYS SPECIFY MODEL AND SERIAL NUMBER OF APPARATUS.
ANM4784 ENCORE
®
700 METERING PUMP - PARTS LIST
Simplex Gearbox Assembly
440.400.000.010D
ISSUE 5 1-10
WT.440.400.001.UA.IM.1012
