ENCORE
®
700 METERING PUMP
KEY NO. LEGACY PART NO. ALT. PART NO. QTY. DESCRIPTION

1
APQ5142
W2T417678
1
Gearbox, Simplex

2
AKC5702
W2T417631
1
Flange, Gear Access, Simplex

3
AXS3656
W2T11182
4
Cap Scr., M8 x 20, Sock. Hd., 316SS

4
ANM4788
W2T417655
1
Bushing Drive, Simplex, LMAD
(5" and 6-1/2" Liquid End Only)

5
ALI3193
W2T367049
1
Oil Seal, 30 x 55 x 7 , BUNA-N

6
AIC4251
1
Bearing, TPRL, 30 x 62 x 21.25mm

7
AMG3448
W2T367066
1
Bearing, TPRL, 20 x 47 x 15.25mm

8
AHS4651
W2T417611
0
Grease, Sunaplex, #992EP

9
ATI3247
W2T417689
2
Pin, Dowel, 6 x 16, M6, Hardened

10
AUK3561
W2T11169
5
Cap Scr., M6 x 20, Sock. Hd., 316SS
(5" and 6-1/2" Liquid End Only)

11
AQC3041
W2T417685
0
"Locktite" Sealant, TL-242

12
AAA1373
W2T11031
1
Shim (.79mm Thk.) Wormshaft

15
AAA1388
W2T11029
2
Shim (.13mm Thk.) Wormshaft

16
AIC4878
W2T417621
1
Bushing, Tail, LMAD

17
AKG5547
W2T417641
1
Nut, Preload

18
ALE4774
W2T11422
1
O-Ring, #152, BUNA-N

19
ARQ3426
W2T11452
5
Bearing, ANGC, 17 x 40 x 17.5mm

20
AVM3239
W2T11162
1
Washer, Oversized OD, M8

21
AXS3656
W2T11182
1
Cap Scr., M8 x 20, Sock. Hd., 316SS

22
AIC4016
W2T11368
1
Carrier, Bearing, Str. Adj.

23
AJE5116
W2T11441
1
Adjuster, Bearing

24
AAA3920
W2T16994
1
Quad-Ring #4141, Auto
OR
AQO4757
W2T11391
1
O-Ring #141 (BUNA-N) Manual

25
AKG4860
W2T417639
1
Housing, Stroke Adj., LMAD

26
ASG3256
W2T11176
1
Dowel Pin, 20 x 40mm, M8, Hardened

27
AJE4035
W2T367030
1
Crosshead, Diaphragm

28
ARQ4767
W2T11453
1
O-Ring, #138, BUNA-N

29
AJA4780
W2T11333
1
O-Ring, #156, BUNA-N

30
AMG3442
W2T11378
2
Bearing, TPRL., 35 x 72 x 18.25mm

31
ARQ5679
W2T417686
1
Conrod, Splex, Dplex (Mach.)

32
AKG4976
W2T11401
1
O-Ring, #332, BUNA-N

33
AHS4653
W2T11192
1
Plug, R1/2, Socket Head

34
AAA3791
W2T11137
0
Silicone Grease, Light

35
AQC3041
W2T417685
0
"Locktite" Sealant, TL-242

36
AAC4634
W2T416779
1
Plug, Socket, Screw R1/8, 316SS

37
AOO4043
W2T11392
1
Label, Str. Adj., LMAD

38
AAA3769
W2T11314
1
Warning Label, Gearbox

39
AAA3759
W2T11313
1
Warning Label, Liquid End

40
E942
W2T409235
0
Tape, Thread Sealant

41
AAA3726
1
Label, Dataplate, LMAD

43
AAA1902
W2T11026
1
Label, Nameplate, Encore 700
NOTE: e PART OF AOO4751 • PART OF AJE4758 • PART OF ANM4767
0 PART OF AAA9593 D PART OF AAA9596 PART OF APQ4775
(W3T108130) (W3T110122)
PART OF AAA9599 PART OF AIC3164 PART OF AAA9590
(W3T108131) (W3T108129)
WHEN ORDERING MATERIAL, ALWAYS SPECIFY MODEL AND SERIAL NUMBER OF APPARATUS.
ANM4784 ENCORE
®
700 METERING PUMP - PARTS LIST
Simplex Gearbox Assembly
440.400.000.010C
ISSUE 4 1-10
WT.440.400.001.UA.IM.1012
