1.1.5 System components
The following illustration depicts an ACQUITY Arc system stack that includes four
core modules.
Figure 1–1: Instrument modules:
Detector
Column module
Quaternary Solvent Manager-R (QSM-R)
Sample Manager FTN-R (SM FTN-R)
The ACQUITY Arc core system includes these modules:
• Quaternary solvent manager
• Sample manager-flow through needle
