Wayne P250 series User Manual

44
P250AF PARTS LIST
Qty
Req’d
P250AF EPN
P250AF EPLP
P250AF DIN
P250AF DILP
Part No.
Item Description
*NOTE: Only for firing rate of 160,000
Btu/hr or less when finer adjustment at low
rate is required.
60172-002
Motor/Blower Asm (w/o Control Box)
1




61803
Control Box Asm (Incl. Trans. & Relay)
1




61875
Motor/Blower & Control Box Pkg.
1




62406-002
Motor Relay
1




60186-004
Transformer-24V
1




60178-002
Terminal Strip




62510-SER
Air Shutter Asm
1




63566-SER
*Air Shutter Asm (
≤160,000 Btu/hour)
1




62715-003
Air Tube/Housing Asm
1




21724-011
Adjustable Flange & Gasket Pkg.
1




100428-002
Flange Gasket
1




21760-011
Base (Pedestal) Pkg.
1




62246-004
Gas Valve-“EP” Models (Nat.)
1




62256-004
Gas Valve-“EP” Models (LP)
1




62374-004
Gas Valve-“DI” Models (Nat.)
1




62374-PRO
Gas Valve-“DI” Models (LP)
1




62898-001
Orifice Holder Asm
1




Varies
Main Burner Orifice-Nat.
1
Refer to Orifice Chart
Varies
Main Burner Orifice-LP
1
Refer to Orifice Chart
60533
Main Burner Orifice Blank (field drilled)
1




61817
Venturi Asm
1




60748
Flame Retention Ring Asm
1




61818
Flamespreader Asm
1




63062-001
Pilot Burner Asm-Nat.
1




64008-SER
Pilot Burner Asm-LP
1




60375-002
Pilot Shield
1




62261
Electrode/Sensor/Ground Rod Asm
1




62947-003
Ignitor Lead Wire




61455
Bulkhead Union
1




80274-SER
Ignition Control-Fen. 35-630902-007
1




101243-001
Ignition Control-Hon. S87K1008




62245-007
Wire Harness (6 wire)




63375-001
Wire Harness (3 wire)




63103-001
Window Plug (Sight Glass)




