Webasto Thermo Top C

Audi A4 / A5
Ident. No.: 1313525D_EN Status: 25.09.2012 © Webasto Thermo & Comfort SE
16
Connect-
ing heater
inlet
Align hoses. Ensure sufficient distance to
neighbouring components, adjust, if neces-
sary.
Routing in
engine
compart-
ment
25
B
C
26
B
E
A
