Connectingthesensors/displayfunctions
5.2 Displayconguration(LINE)
Press and hold LINE (2 s)
Line:
1: No setting possible
cannot be selected
2: Available for selection:
Difference (IN1 - IN2)
Addition (IN1 + IN2)
3: Volume VOL= Q3 x time
4: Available for selection:
Power
PWR1 = p1 x Q3
PWR2 = (p1-p2) x Q3
