Conguringthemeasuredvaluememory
7. Conguringthemeasuredvaluememory
(MEMORYSET)
The following settings will be undertaken:
• Delete measured value memory
• Congure data format of the measured values
• Congure recording intervals
Menu Setting/
pre-selection
Example Notes
DELETE
MEMORY:
YES, NO YES Delete the measured value
memory
DATA
FORMAT:
ACT
MIN-MAX
ACT Data format of the meas-
ured values
ACT=
Save actual values
MIN-MAX=
Save MIN/MAX values
REC CON-
FIG:
REC RATE
2.000 PTS
2 000 PTS RECRATE=
Setting an individual re-
cording interval
2.000PTS=
Dividing the recording time
in 2 000 recording intervals
REC RATE
UNIT:
ms, s, h ms Pre-selecting time unit
(recording interval)
REC
RATE:
Number 20 Setting 20 ms
When dening ACT values, it is possible that important measure-
ment values will not be saved if the selected recording interval is
too great.
