Recordingmeasuredvalues
RecordingmeasuredvalueswithdefaultPROJECTsettings
In this setting, measurements are made using a dened sensor congu-
ration. This conguration is dened by the user using the PC software.
This avoids false measurements and wrong settings.
The preset parameters are altered in the PC software and transferred to
the measuring instrument.
The following parameters can be set:
Menu Setting/
pre-selection
Notes
REC
NAME>
No:
1 . . 5
Load Test There are max. 5 prede-
ned settings (tests) avail-
able for selection.
INPUT> PILOT PRS Dened sensors are de-
ned for each channel.
WRONG
SENSOR !
USE 150 bar Warns of wrong sensor.
A pressures sensor with
the corresponding FS (full
scale) must be connected
to this channel.
CORRECT
SENSOR!
FS 600 L/min Indicates correct sensor.
The next channel can be
connected.
When all of the sensors are connected, the respective type of record-
ing (START/STOP, POINT, AUTO TRIGGER, MANUAL) is selected and
performed automatically.
