The conversion time will take about 15-30s according to the size of the Gcode file.
After this process, insert the SD card (5) into the SD card slot (6) on the card reader
and connect it to the USB interface on the computer. Copy the saved x3gfile to the
root directory and then eject theSD reader (6).
Insert the SD card (5) into the SD slot in the machine, there are two ways to start
building a project using x3g file.
Method 1: Build a project from SD card (5) when the computer connecting to the
machine
Chick on the second button , the pop-up window will list all the x3g files in the
SD card (7). Choose your file and click “Y” to continue. The ReplicatorG can monitor
the real time progress of your object and the temperature of the nozzle.
Method 2: Build a project offline by the control panel, the specific process in
described in section 6.3 in detail.
5.2.8. Common Used Scripts
The Commonly used function of the scripts comes with the software such as
Filament Change and Plate Leveling. Select the “File-> Scripts” from the menu,
open one script and then click the first button on the tool bar to run the script.
