Setup

50 1449820000/1.4/04.17

4.13 Connection via USB cable

Important information

When you have installed the M-Print® PRO application software, connect the USB cable to the

printer. The printer control software is installed automatically.

Figure 43 Connection –USB cable

C USB cable

D USB port

Figure 44 PrintJet ADVANCED Explorer

1 To add the PrintJet ADVANCED, click the [Add…] button.
