NK280B Parameter Reference
Parameter Name Description
Quadrant Compensation Delay The spikes may not appear exactly at the
four quadrant positions due to mechanical
properties of machine tool, but a little
distance away from the quadrant points.
Estimate the time to travel this distance
and then set the time as the value of this
parameter.
Quadrant Compensation Intensity The larger the value is, the more obvious the
compensation result will be.
Parameters for Tool Compensation
Parameters that will influence the tool compensation function.
For details about the tool compensation function, see NcStudio Function Manual.
Table 11: Parameters Related with Tool Compensation
Parameter Name Description
Enable Cutter Compensation Yes. Enable G41,G42 cutter radius
compensation and G43,G44 cutter length
compensation.
Cutter Compensation Option Specify the Cutter Compensation Type. 1:
Normal type; 2: Intersect type; 3: Insert type.
Cutter Compensation Interfere Type 0: None; 1: Three; 2: More
Cutter Compensation Lookahead Segno Specify the segment number when tool
compensation interfere avoidance is enabled,
with range [3~30].
Parameters for Tool Calibration
Parameters that will influence tool calibration function.
Table 12: Parameters Related with Tool Calibration
Parameter Name Description
Cali Mode Tool calibration mode. 1: Auto measurement
mode (namely the fixed tool calibration); 2:
First and exchange calibration mode.
Fine Tool Cali Times Fine calibrating times when the tool
approaches to the surface of tool sensor.
Rough Speed of Cali. The speed when the tool approaches the
surface of tool sensor for the first time.
52
