Instructions for Assembly
Item number 116519-0000 Subject to technical modifications
Version 4 23.04.2014 Page 30/47
Cassita II/Cassita II LED
5.7 Installing the receiver box
The reciever box is always fitted on the same side as the motor.
1.
Installing the receiver box
1. From the inside, slide the receiver
box (1) into the opening on the wall
bracket (2).
2. Affix the receiver box to the wall
bracket using the self-tapping screw
(3).
3. Mount the wall bracket cover profile
(4) to the wall bracket.
