Installation and operating instruction
Gas burner WG30…/1-C ZM-LN
6 Operation
83299902 1/2019-02 La
38-124
6.3 Linearisation
During commissioning it is possible to carry out linearisation of the operating points
in gas operation.
During linearisation a straight line is generated from the operating point displayed
to P9. The values on the straight are adopted as the new operating points.
Initiate a calculation after P9
Press [ENTER].
Combustion manager changes to linearisation mode.
The linearisation mode can be interrupted using the[-] key.
Confirm with[+] key.
Linearisation is initiated.
Example:
1 Calculation from P1 to P9
2 Calculation from P5 to P9
