Weishaupt WG30 1-C ZM-LN Series User Manual

Installation and operating instruction
Gas burner WG30…/1-C ZM-LN
9 Servicing
83299902 1/2019-02 La
76-124
9.6 Service position
Observe notes on servicing [ch.9.1].
The burner mounted rotated by 180° cannot be placed into the service position.
Remove mixing head [ch.9.3].
Unplug plug4 from ignition unit.
Remove cover2 and remove plugs.
Remove hoses3.
Hold housing cover and remove screws1.
Place housing cover onto hanging bolts5.
1
2
4
3
5
