Weishaupt WL20/2-C Z User Manual

Installation and operating instruction
Oil burner WL20/2-C Z
3 Product description
83307702 1/2019-04 La
17-80
3.4.7 Dimensions
Burner
–weishaupt–
179 mm
393 mm
1
358 mm
376 mm
120 mm 182 mm
31 mm
285 mm
1 170 mm without combustion head extension
270 mm with combustion head extension (100 mm)
370 mm with combustion head extension (200 mm)
470 mm with combustion head extension (300 mm)
