Installation and operating instruction
Oil burner WL20/2-C Z
9 Servicing
83307702 1/2019-04 La
47-80
9.8 Removing the air regulator
Observe notes on servicing [ch.9.1].
Remove actuator plug 5.
Place burner into service position A [ch.9.3].
Remove bolts 1.
Remove intake housing 3.
Remove bolts 4.
Remove air regulator 2.
4
5
1
2
3
