Weishaupt WL20/2-C Z User Manual

Installation and operating instruction
Oil burner WL20/2-C Z
9 Servicing
83307702 1/2019-04 La
45-80
9.6 Removing the mixing head
Observe notes on servicing [ch.9.1].
Remove solenoid valve plug1.
Unplug ignition cable 5.
Remove oil line 3.
Remove flame sensor4.
Undo screws 2.
Turn mixing head to the left up to the recess and remove.
5
2
4
3
1
