Weishaupt WL20/2-C Z User Manual

Installation and operating instruction
Oil burner WL20/2-C Z
13 Spares
83307702 1/2019-04 La
67-80
Pos. Description Order No.
2.01 Motor ECK04/A-2 230 V / 50 Hz 652 084
2.02 Screw M5 x 12 Torx-Plus 409 278
2.03 Capacitor set 8.0 µF 420 V, 2.8-standard 713 476
2.04 Fan wheel TLR-S 160 x 61, 6-L-E S1 50 Hz 241 210 08 032
2.05 Grub screw M6 x 10 DIN 914 45H- 420 630
2.06 Air damper complete 241 210 02 022
2.07 Bearing for air damper shaft 241 110 02 107
2.08 Shaft air damper - angle drive 241 210 02 057
2.09 Angle drive spring 2 241 110 02 062
2.10 Screw 4 x 12 Torx-Plus Remform 409 320
2.11 Shaft angle drive - actuator 241 400 02 157
2.12 Frame for actuator 241 210 02 037
2.13 Screw 4 x 30 Torx-Plus Delta PT 409 325
2.14 Actuator STD 4.5 24V B0.36/6 4NL 651 102
2.15 Screw 4 x 35 Combi-Torx-Plus Remform 409 355
2.16 Air regulator spring 2 W20C 241 210 02 072
2.17 For installation rotated by 180°:
– Shaft 240 110 02 017
– Actuator adapter 230 110 02 012
– Screw 4 x 12 Torx-Plus 20IP Remform 409 320
– Screw M4x30 Torx-Plus metric 409 245
