Weishaupt WL20/2-C Z User Manual

Installation and operating instruction
Oil burner WL20/2-C Z
13 Spares
83307702 1/2019-04 La
69-80
Pos. Description Order No.
3.01 Pump ALE V30 601 857
– Filter set with seal 601 107
3.02 Solenoid coil T80 Suntec 220-240V 50-60Hz 604 495
3.03 Plug coupling for motor 652 135
3.04 Oil line pump-nozzle assembly 241 210 06 018
3.05 Screwed union 24-TX-L06-P-ST 452 117
3.06 Oil line 4 x 1 241 210 13 078
3.07 Screwed union 24-SX-LL04-ST 452 020
3.08 Threaded socket cpl. 4 x G
1
/8 x 35 241 210 13 022
3.09 Solenoid valve 121Z2323 230V/50Hz,240V/60Hz 604 480
– Solenoid coil 483764 T1 230V/50Hz,240V/60Hz 604 453
3.10 Screwed union XGE G
1
/8A-4LL with aperture 0.9 241 210 13 107
3.11 Sealing ring A 10 x 13.5 x 1, DIN 7603, Cu 440 027
3.12 Pressure hose DN 4, 286 mm
(for installation rotated by 180)

491 246
3.13 Bypass plug BUZ 06-LL with nut 241 100 06 012
3.14 Oil hose DN 4, 1200 mm
– Standard 491 126
– diffusion resistant 491 131
