Weishaupt WL20/2-C Z User Manual

Installation and operating instruction
Oil burner WL20/2-C Z
13 Spares
83307702 1/2019-04 La
75-80
Pos. Description Order No.
5.01 Combustion manager W-FM 10, 230V Series C 600 475
– Micro fuse T6.3H, IEC 127-2/5 483 011 22 457
5.02 Adapter ring 22 x 4 for extension 600 358
5.03 Reset button extension AGK20.19 600 357
5.04 Cover clip AGK63 600 312
5.05 Bridging plug No. 12, 3 pole 241 050 12 032
5.06 Plug unit ST18/7 716 549
5.07 Plug unit ST18/4 716 546
5.08 Plug-in switch ST18/4 version Z 130 103 15 012
5.09 Ignition unit type W-ZG01V 230 V 100 VA 603 221
5.10 Screw M4 x 42 Combi-Torx-Plus 20IP 409 260
5.11 Plug cable No. 3 motor 241 050 12 062
5.12 Plug cable No. 5 stage 1 solenoid valve 241 210 12 012
5.13 Plug cable No.1 solenoid valve 2 241 210 12 032
