Welbilt MERRYCHEF conneX User Manual

106
Merrychef conneX
®
service and repair manual
7 Circuit boards and diagrams
Back to contents >
7 CIRCUIT BOARDS A ND DIAGRAMS
Terminal
Name
X514
LH Magnetron overheat thermostat. Wires 74 & 73
X515
Not used – Linked out (jumper)
X516
Not used – Linked out (jumper)
X517
Not used
X518
Not used
X519 Convection fan speed controller (VFD) signal
Wire 66 red, 0-10V
Wire 67 green, 10V
Wire 68 blue, GND
X520
Not used
X521
Not used
X522 Not used
X523 UI communication and power cable
X524
Not used
X530
Cavity temperature thermocouple
X531
Not used
X532
Not used
X533
Not used
X534
Not used
X535
Not used
X540
Not used
X541
Not used
X560 Not used
X600 PM
GND
Chassis ground
Note: IO Board test points (TP1 to TP58) are for factory build procedures only.
