Wellav CMP201D - CM2-QAMA-R01;R01 A Output Settings

CMP201D User Guide
83
CM2-QAMA-R01>Basic Setting
Click the Apply button on the right side to make the change take effect.
Name
Range
Name
Range
Symbol Rate (KBaud)
3780~5217
PSI/SI Interval (ms)
50~10000
RF level
25~45dBmV/85~105dBμV
Frequency (KHz)
48000~862000
QAM Mode
QAM16/32/64/128/256
CM2-QAMA- R01/R01A>Output
QAM Output will be different from the Receiver and Encoder module. Since the QAM module is an
output module like IP output, all service configured in receiver, encoder and IP input will be seen
here.
 TS setting: Please refer to IP output service configuration.
