9 Start-up
9.4 Determining sweeping direction WR 870 Honda | PRO
TheRadialSweeperisequippedwitharobustmechanismforreversing
thedirectionofrotation.Thedesireddirectionofrotationissetbyme-
ansofahandlever,whichcanbeeasilyreachedfromthenormalworking
position.
Pulltheleveruptoremovetheretainingpinfromthehole.Nowswing
theleverintothedesiredpositionandthenpushtheretainingpininto
theprovidedhole.
Sincethepowertransmissionfromtheenginetothebrushelementisvia
aV-beltdrivethatrequiressomefriction,youshouldpressthedirection
selectorleverinthedesireddirectionuntilthereisanoticeableresis-
tance(noforcenecessary)andthenxitinthehole.Dependingonthe
degreeofwearofthebelt,itmaybenecessaryafteracertainperiodof
usetoxtheleverinthenextadditionalhole.
   Beforechangingthedirectionofrotation,youshould
   stopthebrushbymovingthelevertotheneutral
   position(seeaboveinthemiddle)toavoidunneces-
   sarybeltwear.Thenpositiontheleveragainsothat
   thebrushelementturnsinthedesireddirection.
(Fig. 14 - Determine the direction of sweeping)
NOTICE
