12 Maintenance and servicing
12.6.1 Replacement of change-of-direction belt WR 870 Honda
(Fig. 24 - Replacing the direction change belt)
12.6.2 The clockwise V-belt / toothed belt (internal combustion engine only)
Ifnecessary,loosenthetensioningscrewonthetopofthehousingoftheV-belt/
timingbelt,sothatyoucanleveroutthetoothedbeltfromthegrooveofthe
drivedisc.Nowitcanbereplacedwithanewtoothedbelt.
Drivebeltlabel:Ax38/X13x965Li
Pleaseonlyuseoriginaltoothedbeltsfromauthoriseddealers!
MakesurethattheV-belt/toothedbeltrunswithitsteethoutwardsoverthe
guiderollerandthedrivepulley.Thetoothedsideshouldengageinthegroove
ofthemotordrivepulley.Whenadjustingthetension,pleaseusethetensioning
screwonthetopofthehousing.
  Thetoothedbeltmayonlybestretchedsofarthatpower
  transmissiononlyoccurswhenthelevertochangethe
  directionofrotationispulledandtheconnectedsweeping
  directionguiderollerisaected.
  Intheneutralpositionoftheguideroller,theV-belt/
  timingbeltshouldbeabletoslideovertheguiderollerand
  drivepulley.
Drivebelts
Guideroller
*Thetensioningscrewislocated
onthetopofthehousing
Motordriveplate
clockwisetoothedbelt
Sweeptingdirectionguideroller
anti-clockwisetoothedbelt
Drivepulleyforbelt
Drivepulley
NOTICE
