12 Maintenance and servicing
12.6.3 The V-belt rotating clockwise (only internal combustion engine)
Dismantlingtakesplaceafterremovaloftheanti-clockwiseV-belt/toothed
belt.Afterdisassemblingtheabove-mentionedbelt,removethetwoscrews
ofthebeltguideplate.
ThenyoucanprytheV-beltfromtheenginedrivepulleyandthedrivepulley
andreplaceitwithanewV-belt.InstallthenewV-beltinthegrooveofthe
enginedrivepulleyanddrivepulleyinreverseorder.
Finally,mountthebeltguideplate,theanti-clockwiseV-belt/toothedbelt
andthedrivebeltaccordingtothetechnicalspecicationsinthisoperating
manual.
Beltguideplate
(Fig. 25 - Replacement clockwise belt)
