Features
Mobile & Versatile
• Large LCD display
• Easy to read in low light and direct light conditions
• Weather-proof, stainless steel enclosure suitable for outdoor use
• MENU key accesses tickets and macro functions
Multiple Power Inputs
• Direct AC Power
• 4 “D” cell alkaline batteries (Up to 500 hours)
• 12 Volt input terminal for car batteries and power adapters
Easy to Use & Service
• Flashlight style battery compartments
• Easy to navigate software menu and calibration
• Calibrate to any test weight value
• Terminal wiring
Advanced Capabilities & Quality
• DYNArrest digital filtering system for fast and stable dynamic weighing
• MACRO II Ticket System for customized scale tickets
• Made In Canada with 2 Year Warranty.
Specifications
Excitation: 5 VDC, Up to 4 x 350 Ω load cells (8 x 700 Ω)
Analog Input Range: 0 - 39 mV
Resolution: 1 million (Internal counts)
10,000d Class III / IIIL (NTEP);
10,000d Class III; 20,000d Class IIIHD (M. Can.)
Measurement Speed: 10 - 80 weight samples/sec. (Automatic)
Power: Battery: 4 "D" cell alkaline batteries
AC Input: 90 - 240 VAC
DC Input: 12 VDC
Consumption: 500 mW (Rated 5W)
Display: 6 digit, 7 segment, LCD display with backlight
1-1/8
th
inch digits (29 mm)
Communications: Full duplex RS-232 serial port
Configurable data format
Selectable output strings & tickets
Temperature Range: 14°F to 104°F / -10°C to 40°C
Approvals: NTEP & Measurement Canada Approved
