DISPLAY & ANNUNCIATORS
The MAX uses a Liquid Crystal Display (LCD) with an LED backlight. HTN
technology gives the display better contrast over wider viewing angles. LCD
arrow and display annunciators communicate scale status and mode information
to the user.
Weight Display
• 6 digits (7 segments each). Up to 3 decimal points.
• Negative weights are indicated by a minus sign (-) on the far left character.
Arrow Annunciators
CENTRE ZERO: The scale is within ±0.2 graduations of TRUE
ZERO.
MOTION: The scale is IN MOTION (the weight is changing).
GROSS: The scale is in GROSS weighing mode.
NET: The scale is in NET weighing mode (a tare weight is stored).
DYNAMIC: The scale is weighing in DYNAMIC mode (if enabled).
MAX Display
