INSTALLATION
Pre-Installation
It is always good practice to verify that your Western MAX indicator is complete
and undamaged upon receipt.
• Check over packaging for any signs of damage.
• Remove the MAX from protective packaging and check for damage.
• Verify that the box includes the MAX indicator complete with:
o User Manual;
o Mounting bracket and thumb screws;
o Note: Batteries not included.
Mounting Instructions
1. The MAX can be mounted to horizontal or vertical surfaces using the
mounting bracket.
2. Ensure that mounting structures (walls, posts, etc.) will bear the weight of
the indicator (Approx. 3 kg / 7 lb with batteries).
3. Use proper hardware, including wall anchors where necessary, when
mounting the bracket and indicator.
Plugging In
1. Plug the AC power cord into a power outlet.
2. Installers must take proper steps to prevent noise, static, or other power
problems.
ATTENTION! In noisy industrial environments, power-
conditioning filters are a requirement to ensure a fail-safe
operation under all conditions. Indicators should not share AC
power with electrical motors and switchgear. Consult the site
engineer for clean AC power.
CAUTION! HIGH VOLTAGE! Only trained personnel should
access any internal wiring and/or components.
