Instruction for use Examination and treatment table Easy Care
** Depending on model and configuration
D2151_01 - 09/2017 16/38
6.5 Display of the infra-red radiant warmer
11.1 Key legend heating.
11.2 Key legend heating illumination.
11.3 Key legend Timer.
11.4 Intensity selection display::
An LED spot indicates the selected intensity
respectively heating capacity.
11.5 Selection display for the automatic intensity
reduction. At an intensity selection >10 mW/cm²
a second, green LED spot indicates up to which
radiation intensity respectively heating capacity
the radiant warmer heats during automatic
intensity reduction.
11.6 Numeric intensity selection display.
11.7 Actual intensity display.
11.8 Balance time to automatic intensity reduction (will only be displayed in case of intensity selection
> 10 mW/cm²).
11.9 Idle.
11.10 Brightness display of dimmable illumination.
11.11 Display of timer.
11.12 Message window.
(If there are no messages, the window will show "CERAMOTHERM“.)
11.13 Display of heating pulse.
The radiant warmer has an ambient light sensor (12). When the ambience darkens, e.g. at night, the bright-
ness of the display is reduced as well. When the ambience brightens up, the brightness of the display is
increased.
Take care that the ambient light sensor (12) is not covered.
