Instruction for use Examination and treatment table Easy Care
** Depending on model and configuration
D2151_01 - 09/2017 7/38
4. Requirements of the location
The examination and treatment table Easy Care is suitable for clinical use in medical areas. It can be
used under the following operation conditions:.
Ambient temperature: 18 to 30°C
Relative air humidity: 15 to 90 % (no condensation)
Atmospheric pressure: 860 to 1100 hPa.
The device is not suitable for the use in explosion-hazardous areas.
The device is not suitable for domestic use.
The examination and treatment table Easy Care must not be operated close to strong or high-frequent
electro-magnetic radiation sources such as HF surgery devices, MRT or similar. Under unfavourable
conditions this could cause faults.
The ambient conditions for the examination and treatment table must in no case be influenced by
warming or air condition devices. The selected values are distorted.
Sunlight, draught, cold exterior walls and windows close to examination and treatment table will impair
the patient's temperature balance.
In case of height-adjustable devices no objects must be placed in the moving range which could cause
collision.
No fluids must be placed above the radiant warmer which in the case of fault might flow into the
device.
For fire prevention take care that there is no inflammable material (e.g. curtains) within 50 cm around
the radiant warmer.
5. Structure and operating principle
The examination and treatment table Easy Care consist of the following components assemblies:
1.1 Smooth double castors
3 x total lock
1 x steering lock
1.2 Electrical distribution
1.3 Height-adjustment**
2. Patient deck with 3 raised sides
2.1 Pad with upholstered sides walls
3.1 Drawer underneath the patient deck
3.2 Shelf fixed at the pillar**
3.3 Drawer fixed at the shelf**
for adapting upgrade items and accessories, e.g.
4.1 Shelf **
4.2 Instrument rail **
For further accessories refer to chapter 9.1
5. Infra-red radiant warmer
